Product Details:
|
| Material:: | Ceramic | Colour:: | White |
|---|---|---|---|
| Rated Voltage:: | DC750V | Rated Current:: | 400A |
| Breaking Capacity:: | DC10KA | Standard:: | UL248-13、ISO8820、 JASO-D622、IEC60269、ROHS |
| Usage:: | PV Moduel,Charging Pile,Automotive | Keyword：: | PV Moduel Fuse |
| High Light: | ISO8820 NH Type HRC Fuse,DC750V NH Type HRC Fuse,ISO8820 automotive cartridge fuse |
||
European Square Fuse 750volt DC Fuse Low Current Fuse Cartridge Fuse
Material:
Noumenon: Ceramic
Pins: Alloy
Features:
Pv Inverter Fuse
Many kinds of Pv Inverter Fuse
Current rating: 400A
Voltage rating: 750VDC/690VAC
Breaking capacity:DC10KA
Product Presentation:
|
Rated Voltage
|
58VDC |
Type Protection
|
Time-lag |
| Rated Current | 10A-500A |
Breaking Capacity
|
DC2700A |
|
Meet the Requirement |
UL248-13,ISO8820,JASO-D622, EU and Rosh Directive |
Remarks |
UL |
Overall dimensions of the product(mm)
Manufacturing material of Automotive Fuse
|
Component name |
Material |
|
Contact the foot |
Copper alloy |
|
Noumenon |
Electric wood shell |
Performance criteria of Automotive Fuse
| Load testing time | Opening time | |
| 10A～500A | ||
| min | max | |
| 110% | 14400 | ∞ |
| 160% | 10 | ∞ |
| 200%(200A and below) | 0 | 100 |
| 200%(200A above) | 0 | 300 |
| 250%(200A and below) | 0 | 60 |
| 250%(200A above) | 0.8 | 120 |
| 600% | 0.02 | 10 |
| Model | Product code | Rated current | Installation requirement |
| DNN-X | DNN-X-35 | 35 | Installation bolt M8, recommended torque 10N·m |
| DNN-X-40 | 40 | ||
| DNN-X-50 | 50 | ||
| DNN-X-60 | 60 | ||
| DNN-X-80 | 80 | ||
| DNN-X-100 | 100 | ||
| DNN-X-125 | 125 | ||
| DNN-X-130 | 130 | ||
| DNN-X-150 | 150 | ||
| DNN-X-175 | 175 | ||
| DNN-X-200 | 200 | ||
| DNN-X-225 | 225 | ||
| DNN-X-250 | 250 | ||
| DNN-X-275 | 275 | ||
| DNN-X-300 | 300 | ||
| DNN-X-325 | 325 | ||
| DNN-X-350 | 350 | ||
| DNN-X-400 | 400 | ||
| DNN-X-425 | 425 | ||
| DNN-X-450 | 450 | ||
| DNN-X-500 | 500 |
