Product Details:
|
| Material: | Ceramic | Color: | White |
|---|---|---|---|
| Rated Current: | 5A-200A | Rated Voltage: | 32VDC/58VDC/80VDC |
| Breaking Capacity: | DC1500A | Category: | AR |
| Keyword: | Electric Vehicle Fuse | Application: | Short-circuit Protection Fuses Of Pure Electric Vehicles And Hybrid Electric Vehicles |
| High Light: | DC1500A Ceramic Automotive Fuses,EV Low Voltage Fuses,58VDC Electric Vehicle Fuses |
||
58VDC ceramic automotive fuses supplier in China
Product details of the 58VDC ceramic automotive fuses
This 58VDC ceramic automotive fuses is our DNQ series flat type fuses,the DNQ series are suitable line in circuit of 32VDC/58VDC/80VDC,rated current range of 5A-200A,breaking capacity up to DC1500A.The dimension and performance conform to UL248-20,ISO8820,JASO-D622,RoHS compliant and the installation available in M6 bolt.
Product type of the DNQ series fuses
|
Model |
Rated current |
Rated voltage |
Breaking Capacity |
| DNQ-A | 5A～200A | 32Vdc | 1.5KA |
| DNQ-X | 5A～200A | 58Vdc | 1.5KA |
| DNQ-H | 5A～200A | 80Vdc | 1.5KA |
| DNM-A | 5A～200A | 32Vdc | 1.5KA |
| DNM-X | 5A～200A | 58Vdc | 1.5KA |
| DNM-H | 5A～200A | 80Vdc | 1.5KA |
Dimension of the DNQ series fuse
Performance test requirements of the DNQ series fuse
|
Current testing (A) |
minimum time (s) |
Max time (s) |
| 75% | 360000 | - |
| 200% | 0 | 300 |
| 600% | 0 | 1 |
Material of the DNQ series fuse
|
Component name |
Material |
|
Contact the foot |
Kirsite Copper alloy |
|
Noumenon |
Ceramics |
