Product Details:
|
| Material: | Ceramic | Color: | White |
|---|---|---|---|
| Rated Current: | 6A-700A | Rated Voltage: | DC750V |
| Breaking Capacity: | DC20KA | Category: | AR |
| Executive Standard: | UL248-20、ISO8820、JASO-D622、GB/T13539、RoHS Compliant | Appliaction: | Electric Vehicle Drive Power System, Power Conversion System |
| High Light: | Hybrid EV Ceramic Fuses,RoHS Compliant Ceramic Fuses,Ceramic Automotive Fuses DC20KA |
||
DC20KA BS88 series ceramic fuses in China
Product description of BS88 series fuse
|
Rated Voltage |
DC750V or lower |
Type Protection |
aR |
| Rated Current | 6A-700A |
Breaking Capacity |
DC20KA |
|
Meet the Requirement |
UL248-20,ISO8820,JASO-D622,GB/T13539,RoHS compliant |
Remarks |
UL,CCC |
Application of the BS88 series fuse
This BS88 series fuses for applications in Electric Vehicles (EV) or Hybrid EV are relatively new in the industry and they could be regarded as a crossover product between low voltage fuse and automotive fuse.
Dimension of the BS88 series fuse
Electrical parameters
| Model | Code |
Rated Current A |
100% voltage drop mV |
| HBD-EPL | HBD-16EPL | 16 | 266.6 |
| HBD-EPL | HBD-20EPL | 20 | 317.4 |
| HBD-EPL | HBD-32EPL | 32 | 253.5 |
| HBD-EPL | HBD-40EPL | 40 | 224.4 |
FAQ
Question:Is this BS88 series products sufficient inventory?
Answer:Most of our BS88 series products have inventory. Except for individual currents, there is no inventory, but it is generally sufficient material, and the production date is also short.
