Product Details:
|
| Material: | Ceramic | Rated Current: | 10A-500A |
|---|---|---|---|
| Rated Voltage: | 500VDC | Breaking Capacity: | DC20KA |
| Type Of Protection: | AR | Application: | Energy Storage Capacitor, Frequency Conversion Controller |
| Keyword: | Charging Pile Fuse | Executive Standard: | UL248, GB13539, IEC60269, GB31465 |
| High Light: | Charging Pile EV Fuses,150A Short Circuit Fuse |
||
aR protection 150A EV fuses purpose designed for charging pile system
Product introduction of the EV fuses
This series fuse are ceramic bolt type fuse,mainly designed for energy storage system,low speed vehicle(BDU,PDU,pack,MSD,charging pile,charging module system),solar inverter etc.We are Dissmann Fuse for nearly 10 years of deep cultivation in charging pile filed,it has become the main supplier of many leading companies.The rated current range of the EV series fuse is 10A to 500A,rated voltage is 500VDC,breaking capacity up to DC20KA.
Structure of the EV fuse
The fuse tubes of electric vehicles are made of high temperature resistant ceramic materials, which have high fire resistance and solid hardness.
The melt is sealed in a smelting tube so that 99.99% of the pure silver becomes a variable cross section melt. The smelting pipe is filled with chemically treated high purity quartz sand and specially treated chemical materials for arc to extinguish agglomeration.
Dimension of the EV fuse
Paking of EV fuse
Piece Weight: 246±5g
Carton Dimension: L.274*W.225*H.230mm
Inner Box Dimension: L.225*W.140*H.50mm
Net Weight/Carton: 12.3kg
Gross Weight/Carton: 13.5kg
Carton Dimension:14180cm3
Nomal working conditions
Normal using conditions: -5°C ~ 60°C
Permitted conditions: -55°C ~ 120°C
FAQ
Question :What Advantages do your Fuses have?
Answer:High impact resistance, Low temperature rise, Low power consumption, Stable thermal resistance, Low derating, Low attenuation in high temperature environment.
