Product Details:
|
| Material: | Ceramic | Color: | White |
|---|---|---|---|
| Rated Current: | 10A-500A | Rated Voltage: | DC32V/DC58V/DC80V |
| Type Protection: | AR | Intsallation: | Bolt On |
| Breaking Capacity: | DC2700A | Certification: | UL |
| High Light: | DC2700A Bolt Type Fuse,32VDC Ceramic Bolt Type Fuse |
||
32VDC ceramic bolt type fuse supplier
Product description of 32VDC fuse
This series fuses designed for low speed electric vehicles, motors and charging modules for their resistance to vibration and impact.The 32 volt DC style bolt down fuse has an interrupting rating of DC2,700 amps and is available from 10 to 500 amps.We are Dissmann Fuse with more than 20 years experience,The design, testing, production and quality control of all products come from our team. We control the core technology and quality of products.
Meet the requirement of 32VDC fuse
This 32VDC ceramic bolt type fuse dimension and performance conform to UL248-13,ISO8820,JASO-D622,RoHS compliant.
Cooperation partner
At present our customers are Apple, Microsoft, DELL, LG, Samsung, Siemens, Amphenol, BYD, CATL, Zotye Auto, Leadway Auto, etc.
Dimension of the 32VDC fuse
Manufacturing material
| Part | Material |
| Fuse wire | Copper or Silver |
| End cap | Copper alloy tin plating |
| Fuse leg | Copper alloy tin plating |
| Fuse body | Ceramic Tube |
| Filler | Quartz sand |
