Product Details:
|
| Rated Voltage：: | DC1000V Or Lower | Protection Type：: | AR |
|---|---|---|---|
| Breaking Capacity：: | DC50kA （time Constant ≤10ms） | Comply With :: | EU And China RoHS Directives |
| Meet The Requirements:: | UL248, ISO8820 And JASOD622 | TUV Certification No.: | B 113737 0001 |
| High Light: | EV Charger 1000VDC Fuse,MEV-J Ceramic Automotive Fuses |
||
Basic information
Appearance and installation dimension of the fuse(mm)
Product type that you can choose:
| MEV-J 1000VDC | ||||
| Product code | Rated current A | I²t(A²Sec) | power consumption | |
| Pre-arc | Total | W | ||
| MEV-J-C20 MEV-J-C21 MEV-J-C30 MEV-J-C31 MEV-J-D23 |
50 | 140 | 680 | 13 |
| 63 | 250 | 1300 | 15 | |
| 80 | 510 | 2550 | 20 | |
| 100 | 1100 | 5200 | 28 | |
| 125 | 2000 | 9800 | 32 | |
| 160 | 4100 | 20000 | 38 | |
| 200 | 8500 | 42000 | 44 | |
| 250 | 13000 | 60000 | 48 | |
| 300 | 18000 | 90000 | 53 | |
| 315 | 23000 | 110000 | 60 | |
| MEV-J-D20 MEV-J-D30 MEV-J-D23 |
350 | 24000 | 125000 | 70 |
| 400 | 38000 | 190000 | 80 | |
| 450 | 53000 | 260000 | 85 | |
| 500 | 69500 | 340000 | 95 | |
Service conditions
Normal use conditions and parameter correction.
The fuse operates under the following normal conditions of use, without additional correction.
When the normal use conditions are exceeded, if they are within the allowable use conditions, some parameters may need to be corrected or consulted. If the scope of allowable use conditions is exceeded, our company should be consulted and the work adaptability evaluation and test of the conditions should be carried out.
It is recommended that the current value of long-term current flow should not be greater than 80% of the rated current.
