MEV High Current Fuse , DC1000V 500A Ceramic Automotive Fuses

Large Image : MEV High Current Fuse , DC1000V 500A Ceramic Automotive Fuses

Product Details:

Place of Origin:	China
Brand Name:	Dissmann
Certification:	UL248-13、ISO8820、JAS0-D622、IEC60269、RoHS
Model Number:	MEV-J-Dxx

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiable
Packaging Details:	Standard Carton Packing
Delivery Time:	5-8 days
Payment Terms:	L/C, T/T
Supply Ability:	1000000pcs

Contact Now

MEV High Current Fuse , DC1000V 500A Ceramic Automotive Fuses

Description

Rated Voltage:	DC/AC1000V	Rated Current:	350A-500A
Meet The Requirement:	UL248-13,ISO8820,JASO-D622,IEC60269 RoHS	Type Protection:	AR
Breaking Capacity:	DC50KA	Remarks:	TUV
High Light:	500A High Current Fuse , MEV High Current Fuse , Ceramic Automotive Fuses DC1000V

^{High Current Ceramic Automotive Fuse MEV-J-Dxx Series Fuse}

^{1. Basic Specifications:}

Rated Voltage

DC/AC1000V

Type Protection

Rated Current

350A-500A

Breaking Capacity

DC50KA

Meet the Requirement

UL248-13,ISO8820,JASO-D622,IEC60269

RoHS

Remarks

TUV

2. Overall Dimensions:

High Current MEV Fuse DC1000V 500A Ceramic Automotive Fuses

Size Model:MEV-J-D20

High Current MEV Fuse DC1000V 500A Ceramic Automotive Fuses

Size Model:MEV-J-D23(Optional microswitch installation)

3. Product Type:

Model	Product code	Rated current A	I²t(A²Sec)		Power consumption W
Model	Product code	Rated current A	Pre-arc	Total	Power consumption W
MEV-J-D20 MEV-J-D23	MEV-J-D20-350	350	10900	73000	50
	MEV-J-D20-400	400	10900	73000	50
	MEV-J-D20-500	500	19500	133000	67
