Product Details:
|
| Rated Voltage: | 32VDC | Rated Cirrent: | 1A |
|---|---|---|---|
| Characteristic: | Fast Acting Fuse | Breaking Capacity: | DC1000A |
| Meet The Requirement: | UL248、ISO8820、RoHS | Application: | Applicable To The Internal Branch Protection Of Automobile Electrical Appliances |
| High Light: | 1A Automotive Blade Fuse,Internal Branch Protection Automotive Blade Fuse,Fast Acting Fuse DC32V |
||
2. Product model of the DC32V 1A Black Automotive Blade Fuse
|
Model
|
Product code
|
Rated current A |
I²t (A²Sec) |
Voltage drop mV |
Pigment
|
| DFN-A | DFN-A-1 | 1 | 0.4 | 174 | (Black) |
| DFN-A-2 | 2 | 1.5 | 140 | (Gray) | |
| DFN-A-3 | 3 | 6.3 | 137 | (Violet) | |
| DFN-A-4 | 4 | 13 | 135 | (Pink) | |
| DFN-A-5 | 5 | 25 | 125 | (Tan) | |
| DFN-A-7.5 | 7.5 | 56 | 115 | (Brown) | |
| DFN-A-10 | 10 | 110 | 110 | (Red) | |
| DFN-A-15 | 15 | 295 | 102 | (Blue) | |
| DFN-A-20 | 20 | 480 | 96 | (Yellow) | |
| DFN-A-25 | 25 | 1000 | 90 | (Clear) | |
| DFN-A-30 | 30 | 1460 | 86 | (Green) | |
| DFN-A-35 | 35 | 2205 | 88 | (Dark green) | |
| DFN-A-40 | 40 | 3200 | 95 | (Orange) |
3. Current characteristic curve of the DC32V 1A Black Automotive Blade Fuse
