Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses

Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses
Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses

Large Image :  Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses

Product Details:
Place of Origin: China
Brand Name: Dissmann
Certification: UL
Model Number: DFN-H
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Standard Carton Packing
Delivery Time: 5-8days
Payment Terms: T/T, L/C
Supply Ability: 1,000,000pcs

Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses

Description
Material:: Zinc Alloy , Plastic Usage:: Automotive,battery Charge
Rated Voltage:: DC80V Breaking Capacity:: DC1000A
Rated Current:: 1A-40A Fusing Speed:: F
Keyword:: Auto Insert Fuse Standard:: UR,UL
High Light:

Fast Blow automotive replacement fuses

,

DC80v automotive replacement fuses

,

led mini blade fuses

Auto replacement fuse fast blow fuse DC auto mini fuse LED blade fuse



Material:
Noumenon: Ceramic
Pins: Copper alloy



Product Presentation:



Rated Voltage

额定电压

80VDC

Characteristic

特性

F快断
Rated Current 额定电流 1A-40A

Breaking Capacity

分断能力

DC1000A

Meet the Requirement

符合要求

UL248,ISO8820,

欧盟和RoHS 指令

Remarks

备注

UL



产品外形尺寸(mm)/Overall dimensions of the product(mm)



Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses 0



电流特性曲线图/Currentcharacteristiccurve



Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses 1



产品型号/Product type



Model

型号

Product code

产品代码

Rated current

额定电流 A

I²t

(A²Sec)

Voltage drop

电压降 mV

Pigment

颜色

DFN-H DFN-H-1 1 0.4 174 黑色(Black)
DFN-H-2 2 1.5 140 灰色(Gray)
DFN-H-3 3 6.3 137 浅紫色(Violet)
DFN-H-4 4 13 135 粉红色(Pink)
DFN-H-5 5 25 125 浅棕色(Tan)
DFN-H-7.5 7.5 56 115 棕色(Brown)
DFN-H-10 10 110 110 红色(Red)
DFN-H-15 15 295 102 蓝色(Blue)
DFN-H-20 20 480 96 黄色(Yellow)
DFN-H-25 25 1000 90 透明色(Clear)
DFN-H-30 30 1460 86 绿色(Green)
DFN-H-35 35 2205 88 深绿色(Dark green)
DFN-H-40 40 3200 95 橙色(Orange)



性能标准/Performance criteria



测试电流项目

Test current item(A)

电流

Current

最小时间

Minimum time(s)

最大时间

Maximum time(s)

110% 1A-40A 3600
150% 1A-40A 0.500 300
200% 1A-40A 0.150 20
350% 1A-40A 0.040 0.500
600% 1A-40A 0.020 0.100

Product Anatomy:

Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses 2



Test equipment

Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses 3

Production equipment

Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses 4
Fast Blow Automotive Replacement Fuses , DC80V Led Mini Blade Fuses 5
