Product Details:
|
| Material: | Ceramic | Color: | White |
|---|---|---|---|
| Rated Current: | 5A-200A | Rated Voltage: | 32VDC/58VDC/80VDC |
| Breaking Capacity: | DC1500A | Category: | AR |
| Keyword: | Electric Vehicle Fuse | Application: | Short-circuit Protection Fuses Of Pure Electric Vehicles And Hybrid Electric Vehicles |
| High Light: | UL Micro Blade Fuses,32VDC Automotive Fuses,1.5KA Electric Vehicle Fuses |
||
Micro blade fuses DNQ series supplier bolt type
Product details of the DNQ series fuses
This DNQ series fuses are flat type Bolt install connection fuse, with small size, low I²t, high breaking ability characteristics and other characteristics.They are suitable line in circuit of DC32V/58V/80VDC,rated current range of 5A-800A,breaking capacity up to DC1500A.Applicable to frequency converter, rectifier, inverter, various types of power supply and other semiconductor equipment, and power battery, electric motor, capacitor, cable and equipment or component’s short-circuit and back-up protection. This product has good vibration resistance and flame retardant performance. Suitable for vibration environment applications such as rail transit and motor vehicles.
Product type of the DNQ series fuses
|
Model |
Rated current |
Rated voltage |
Breaking Capacity |
| DNQ-A | 5A～200A | 32Vdc | 1.5KA |
| DNQ-X | 5A～200A | 58Vdc | 1.5KA |
| DNQ-H | 5A～200A | 80Vdc | 1.5KA |
| DNM-A | 5A～200A | 32Vdc | 1.5KA |
| DNM-X | 5A～200A | 58Vdc | 1.5KA |
| DNM-H | 5A～200A | 80Vdc | 1.5KA |
Dimension of the DNQ series fuse
Performance test requirements of the DNQ series fuse
|
Current testing (A) |
minimum time (s) |
Max time (s) |
| 75% | 360000 | - |
| 200% | 0 | 300 |
| 600% | 0 | 1 |
Material of the DNQ series fuse
|
Component name |
Material |
|
Contact the foot |
Kirsite Copper alloy |
|
Noumenon |
Ceramics |
