Fiber Material 1000VDC Semiconductor Fuse For Power Systems

Fiber Material 1000VDC Semiconductor Fuse For Power Systems
Fiber Material 1000VDC Semiconductor Fuse For Power Systems Fiber Material 1000VDC Semiconductor Fuse For Power Systems

Large Image :  Fiber Material 1000VDC Semiconductor Fuse For Power Systems

Product Details:
Place of Origin: China
Brand Name: Dissmann
Certification: TUV/CCC
Model Number: HEV-J-Q
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Standard Carton Packing
Delivery Time: 5-8days
Payment Terms: T/T, L/C
Supply Ability: 1,000,000pcs

Fiber Material 1000VDC Semiconductor Fuse For Power Systems

Description
Material: Fiber Color: White
Rated Current: 5A-800A Rated Voltage: 1000VDC
Type Of Protection: AR Breaking Capacity: DC30KA
Application: Pure Electric Vehicles Keyword: EV Charger Fuse
High Light:

Fiber Material Semiconductor Fuse

,

1000VDC Semiconductor Fuse

,

Power Systems Semiconductor Fuses

1000VDC HEV fuse manufacture in China factory

Introduction of the HEV fiber fuse

We're Dissmann HEV series fuses suitable for rated current range of 5A~800A,rated voltage of AC/DC1000VDC,,interrupting rating up to AC100KA/DC30KA at 1000VDC.Most of our customer mainly use to protect power batteries, motors, capacitors,EV charger,wires and other equipment and devices.



Material of the HEV fuse

This fuse end contact mabe by copper alloy,fuse body is glass fiber tube and the filler is quartz sand.



Dimension of the semiconductor fuse,Choose the size according to the rated current.

Fiber Material 1000VDC Semiconductor Fuse For Power Systems 0



Fiber Material 1000VDC Semiconductor Fuse For Power Systems 1



Dimension caode A±2 B±1.5 C±1 D±1.5 E±1.5 F±1 G±0.5 H±0.2 J±1
HF1 124 25 78 100 109 9 18 4 13.5
HF2 117 33 78 93 100 9 22 5 12.5
HF3 139.5 38 83.5 99.5 120 10.5 25 6 20.7
HF4 146.5 50 89.5 106 126.5 10.5 38 6 20.7
HF5 197.5 63 89.5 123.5 162.5 13.5 50 10 33



HF1:rated current range is 5A~80A

HF2:rated current range is 90A~150A

HF3:rated current range is 175A~325A

HF4:rated current range is 350A~500A

HF5:rated current range is 600A~800A



FAQ

Question 1:How to choose a fuse?

Answer:At the beginning,We will send you a customer actual application form.Generally, we need to clear your application field, opperating current and operating voltage, installation methods, certification requirements, and other parameter requirements.
