Product Details:
|
| Material: | PBT | Colour: | Blown |
|---|---|---|---|
| Rated Voltage: | 58VDC | Rated Current: | 1A-40A |
| Interrupting Capacity: | 1KA | Certificates: | UR,UL |
| Characteristics: | Fast-acting | Environmental Protection: | RoHS, Reach |
| High Light: | Automobile Power Distribution Low Voltage Fuses,32v Low Voltage Fuses,UL 40 amp car fuse |
||
Packing:
500pieces/Plastic bag(22*18cm)
1000pcs/Inner Box(23.5*15.5*7.5cm)
5000pcs/Carton(39.5*25.5*18.5cm)
Product Anatomy
Product type
|
Model |
Product code |
Rated current ( A ) |
I²t (A²Sec) |
Voltage drop( mV ) |
Pigment |
| DFN-X | DFN-X-1 | 1 | 0.4 | 174 | Black |
| DFN-X-2 | 2 | 1.5 | 140 | Gray | |
| DFN-X-3 | 3 | 6.3 | 137 | Violet | |
| DFN-X-4 | 4 | 13 | 135 | Pink | |
| DFN-X-5 | 5 | 25 | 125 | Tan | |
| DFN-X-7.5 | 7.5 | 56 | 115 | Brown | |
| DFN-X-10 | 10 | 110 | 110 | Red | |
| DFN-X-15 | 15 | 295 | 102 | Blue | |
| DFN-X-20 | 20 | 480 | 96 | Yellow | |
| DFN-X-25 | 25 | 1000 | 90 | Clear | |
| DFN-X-30 | 30 | 1460 | 86 | Green | |
| DFN-X-35 | 35 | 2205 | 88 | Dark green | |
| DFN-X-40 | 40 | 3200 | 95 | Orange |
Current characteristic curve
Performance criteria
|
Test current item(A) |
Current |
Minimum time(s) |
Maximum time(s) |
| 110% | 1A-40A | 3600 | ∞ |
| 150% | 1A-40A | 0.500 | 300 |
| 200% | 1A-40A | 0.150 | 20 |
| 350% | 1A-40A | 0.040 | 0.500 |
| 600% | 1A-40A | 0.020 | 0.100 |
Product Applications
Test Equipment
Production Equipment
Our Certificates
