Product Details:
|
| Material: | Ceramic | Colour: | White |
|---|---|---|---|
| Rated Voltage: | 150VDC | Rated Current: | 400A |
| Breaking Capacity: | 50kA | Standard: | IEC60269, UL248 |
| Usage: | Overload Protection, Charging Station | Keyword: | Class L Fuse Low Voltage Fuse |
| High Light: | 400A class l fuse,IEC60269 Low Voltage Fuses,600 Volt Low Voltage Fuses |
||
Low Voltage Class L Fuse Is 600 Volt AC Current Limiting Fast Acting Time Delay Fuses
What is a UL Class L, Fuse? A Class L fuse is 600 volt AC current limiting, fuse that is rated to interrupt a minimum of 200,000 amps. Both fast acting, and time delay, versions of the Class L fuse is offered. Dissmann, Bussmann, Littelfuse and Mersen self-certify their top line Class L fuses to a 300,000 amp interrupting rating,. A lower cost version of the Class L time delay fuse is available. The Type L Fuse is UL Listed, under UL 248-10, Class L, (601-6,000 amps) and CSA Certified,. The Type L fuse is UL Recognized, for ampere ratings of 100 to 600 amps.
Data Sheets & Stock Check with our customer service by email or phone.
Dissmann, Bussmann, Littelfuse and Mersen offer Class L fuses. Bussmann uses the Low Peak® and Limitron,® brand names for its Class L fuses. Littelfuse markets its Class L fuse under the POWR-PRO,® brand name. Mersen uses the Amp-Trap,® and Amp-Trap 2000,® brand names.
Dissmann Fuses producing 20 years, UL, TUV, ASTA, CSA, ROHS, REACH Certfiications approved. Numerours Testimonies from customers, if interested, contact us by email or phone.
