MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System
MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System

Large Image :  MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System

Product Details:
Place of Origin: China
Brand Name: Dissmann
Certification: DIN43560/1
Model Number: DNQ-H 80VDC 50A
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Standard Carton Packing
Delivery Time: 5-8 days
Payment Terms: L/C, T/T
Supply Ability: 1000000pcs

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System

Description
Rated Voltage: 80VDC Rated Current: 50A
Protection Type: AR Breaking Capacity: 1.5KA
Installation: Install Bolt M5,Recommend Torque: 2.5N.m UL Certification No.: E496054
High Light:

50A Bolt Down Fuse

,

80VDC Energy Storage System Fuse

Dissmann Bolt-down Fuse 80VDC 50A MINI Size Flat Type Fuse for Li-ion Battery System

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System 0

PRODUCT DRAWING

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System 1

Performance test requirements:

Current testing item Min time(s) Max time(s)
100% 360000
200% 0 300
500% 0 1



TEMPERATURE ASSESSMENT GRAPH:

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System 2



TIME CURRENT CHARACTERISTIC DIAGRAM:

MINI Size Flat Type Dissmann Bolt Down Fuse 80VDC 50A For Li Ion Battery System 3



MANUFACTURING METEARIAL:

Part Material
Fuse wire Copper or Silver
End cap Zinc alloy or copper alloy
Fuse leg Zinc alloy or copper alloy
Fuse body Ceramic Tube
Filler Quartz sand

Storage temperature:

  • Product storage temperature:-40°C~105°C.
  • The relative humidity is not more than 70% at 40 ° C;
  • The relative humidity at 30 ° C is not more than 80%;
  • Under 20 ° C, the relative humidity is not more than 90%.
  • Packaging storage temperature:-40°C~70°C.
  • The relative humidity is not more than 40% at 40 ° C;
  • The relative humidity is not more than 50% at 30 ° C;
  • Under 20 ° C, the relative humidity is not more than 90%, and there is no condensation.
