DC80VDC Ceramic MINI Size Bolt Down Fuse For Energy Storage System UL Certified

Large Image : DC80VDC Ceramic MINI Size Bolt Down Fuse For Energy Storage System UL Certified

Product Details:

Place of Origin:	China
Brand Name:	Dissmann
Certification:	UL248-20、ISO8820、JAS0-D622、RoHS
Model Number:	DNQ-H-1

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiable
Packaging Details:	Standard Carton Packing
Delivery Time:	5-8 days
Payment Terms:	L/C, T/T
Supply Ability:	1000000pcs

Contact Now

DC80VDC Ceramic MINI Size Bolt Down Fuse For Energy Storage System UL Certified

Description

Rated Voltage:	80VDC	Rated Current:	5A-200A
Protection Type:	AR	Breaking Capacity:	DC1500A
Application:	Energy Storage System	Meet The Requirements:	UL248-20、ISO8820、JASO-D622、RoHS
High Light:	DC80VDC Bolt Down Fuse , Energy Storage System Fuse ISO8820

Dissmann DC80VDC Ceramic Fuse MINI Size Bolt-down Fuse for Energy Storage System Fuse UL Certified

DC80VDC Ceramic Fuse MINI Size Bolt-down Fuse for Energy Storage System Fuse UL Certified

DNQ-X Ceramic Fuse Mini Size Fuse for Energy Storage System

Basic information of MINI Size Bolt-down Fuse:

Type:Flat plug type automobile fuse (bolt type installation)
Dimensions and performance conforming to UL248
Rated voltage: 80VDC,
Rated current: 10A~200A,
Breaking capacity: DC1.5kA
Conform to EU and China RoHS directives
The executive standard is UL248, UL certification number: E496054
This series of products are automobile flat plug fuses, which have the characteristics of small size, low power consumption and high breaking capacity. It is applicable to low-speed electric vehicles, motors and charging modules.

Dimension of the DC80VDC Ceramic Fuse:

DC80VDC Ceramic Fuse MINI Size Bolt-down Fuse for Energy Storage System Fuse UL Certified

Products Materials of the MINI Size Bolt-down Fuse:

Component name

Material

Contact the foot

Kirsite

Copper alloy

Noumenon

Ceramics

Products Type of the MINI Size Bolt-down Fuse:

Model	Rated current	Rated voltage	Breaking Capacity
DNQ-A	5A～200A	32Vdc	1.5KA
DNQ-X	5A～200A	58Vdc	1.5KA
DNQ-H	5A～200A	80Vdc	1.5KA
DNM-A	5A～200A	32Vdc	1.5KA
DNM-X	5A～200A	58Vdc	1.5KA
DNM-H	5A～200A	80Vdc	1.5KA
