Product Details:
|
| Material: | Ceramic | Rating Current: | 100A-315A |
|---|---|---|---|
| Rating Voltage: | AC/DC1000V | Breaking Capacity: | DC50KA |
| Type Of Protection: | AR | Related Standard: | UL248-13、ISO8820、JASO-D622、IEC60269、RoHS |
| Application: | Energy Storage System、EV Charger | Installation: | Bolt On |
| High Light: | Energy Storage System Fuse 1000VDC,Dissmann Bolt On Fuses,CE Certificate Bolt On Fuses |
||
1000VDC energy storage system safety protection fuse
Description of the Dissmann®1000VDC fuse
Our Dissmann Fuse model of MEV fuse rating current range is 100A-315A,rating voltage is DC/AC1000V,breaking capacity up to DC50KA at AC/DC1000V,the protection type is aR.The characteristic of the fuse with small size and high breaking capacity.Currently most of our customer mainly use this fuse for battery energy system and EV charger protection.
Structure of the MEV fuse
The tube shape of this MEV fuse is square.The porcelain tube is made of ceramics.The bottom touch knife is copper alloy tin plating,and the inside is composed of melting slices,solid glue and quartz sand.
Dimension of the MEV fuse
Feedback:
1. After receiving items, Buyer’s early confirmation will be highly appreciated
2. Because your feedback is very important for the development of our business, we sincerely invite you to be satisfied with our products and services. Essence
3. Please contact us before leaving any negative or neutral feedback. We will solve any problems with us. Thank you for your understanding.
Dissmann®Factaory Display
Dissmann® Fuse workshop display
FAQ
Question:How to select the current of the fuse?
Answer:Generally, we will calculate our rated current fuse according to 1.5 times of the customer's actual operating current.
